2004A Char-LCD(LCM) 20*4 Words-Support 5V

Rated 5.00 out of 5 based on 3 customer ratings
(3 customer reviews)

$5.10

Out of stock

SKU: ILC1040 Category: Tags: , ,

Description

Well, Compare to 1602A LCD, in one conclusion, both are character-type LCD, but more expensive than 1602 ($7.6 instead of $2.8), but more words you have in the screen (20*4 instead of 16*2).

Feature:

  • Package:COB
  • Mechanical maximum dimension:98 x 60 mm
  • Connection: conducting adhesive-type
  • Screen dimension: 76 x 26 mm
  • Connection: one single row in parallel connection
  • Dot size: 0.55 x 0.55 mm
  • Back-light type: EL/LED
  • Character size: 29.5 x 47.5 mm
  • Operational Volt: +5V/+3.3V
  • Display color: Yellow-Green/Blue/Black & White
  • Operation Temperature: -10 ~ +60 C
  • Controller: SPLC780
  • Storage Temperature: -20 ~ +70 C

Pin Definition:

  • 1 – VSS -Ground for Logic(0V)
  • 2 -VDD -Power supply for Logic(+5V)
  • 3 -V0 -Power supply for LCD Driver
  • 4 -RS -H: Data;L: Instruction Code
  • 5 -R/W -H: Read; L: Write
  • 6 -E -Enable signal
  • 7~14 – DB0~DB7 – Data Bus Line
  • 15 – A Backlight Power(+5V)
  • 16 – K Backlight Power(0V)

Documentation:

Additional information

Weight 0.075 kg
