10PCS 0038B Infrared Transmitter
$1.60
- Description
- Additional information
- Reviews (2)
- Product Enquiry
Description
- Operation voltage are 2.7-5.5V
- Receiving range is 10 – 15 meters.
- Pin pitch are 2.54 mm
- Operating Current: 1.4mA
- Frequency: 38K
- Angle: ± 45 °
- Wavelength: 940nm
- PC838 and HX1838 Pin definition : 1- output, 2- GND, 3-VCC from right to left from front view side, you can connect it directly to your arduino.
- PC838 and HX1838 has EMC shielding.
Application:
- Wide adaptation of voltage, low-power, high sensitivity, excellent anti-interference characteristics;
- Application: household appliances, air-conditioning, toys, infrared remote control receiver;
Additional information
| Weight | 0.01 kg |
|---|
Errol –
This is not transceiver. This is Infrared receiver only.
There is no integrated infrared transmitter
Karsten (verified owner) –
Well documentated recevier (https://www.electrodragon.com/w/HS0038, B-Varaint) Works great with https://github.com/z3t0/Arduino-IRremote
