5 Pairs: Universal IR Receiver Transmitter, HS0038

Description

IR sensor tuned to 38KHz, perfect for receiving commands from a TV remote control.

Runs at 5V (although it seems to be OK down to 3.3V) to use

Wiring: Connect pin 3 (all the way to the right) to 5V power, pin 2 (middle) to ground and listen on pin 1.

It doesn’t do any decoding of the signal, just passes the ‘raw data’ along.

• Size: square, 7mm by 8mm detector area
• Output: 0V (low) on detection of 38KHz carrier, 5V (high) otherwise
• Sensitivity range: 800nm to 1100nm with peak response at 940nm.
• Frequency range is 35KHz to 41KHz with peak detection at 38KHz
• Power supply: 5V DC 3mA

Kit Includes:

• Universal IR receiver (HS0038) * 5pcs
• IR LED transmitter * 5pcs

Documentation please find the entry here.
