[Retired] 8-Channel Relay Module Shield (for Arduino, 5V TTL)
$16.10
- Description
- Additional information
- Reviews (0)
- Enquiry2
Description
With this module, you can control any domestic appliance and high current load devices, is the common choice for controlling prototype.
- Use high current load relay，AC250V 10A DC30V 10A
- Use 5V control relay as default set
- Independent wires layout on relay connection to ensure highest safety
- Standard jack that able to use on any development board
- Keep Arduino 3PIN standard jack setup
- Has screw holes for easy to install
- Suitable for 51/AVR/AVR/ARM, etc platform
Documentation on this page.
Additional information
| Weight | 0.12 kg |
|---|
