MG996R Servo Motor, 12KG Torque

Rated 4.75 out of 5 based on 4 customer ratings
(4 customer reviews)

$4.90

SKU: SCU1012 Category: Tags: ,

Description

  • Fully metal gears, very reliable
  • A dedicated servo for biped robot, robots, remote control cars, remote control boats, gasoline engines.

Specifications:

  • Torque: 12kg/cm(6V), extreme high force.
  • Common GND, VCC, Data connector for most general use.
  •  volt supply,
  • 180 degree movement
  • See more specs in attached pictures
  • Rapid moving speed, 0.2 sec for 60 degree
  • Accessories are for “-” type
  • Reaction speed: 0.17sec/60 degrees (4.8v no load) 0.14sec/60 degrees (6v no load)
  • Operating voltage: 4.8-7.2V for MG996, 3-7.2V for MG995
  • Working temperature: 0°C-55°C
  • Gear form: metal gear
  • 100mA current consumption
  • Working Deadzone: 5us (microseconds)

Currently updated from MG995 to MG996R.

Documentation see on this page.

Additional information

Weight 0.09 kg

4 reviews for MG996R Servo Motor, 12KG Torque

  1. Rated 4 out of 5

    danic (verified owner)

    Goods arrived quickly (belgium post), great service

  2. Rated 5 out of 5

    Christoph (verified owner)

    This servo is really strong. Didn’t measure it, but the metal gears are worth their money.

  3. Rated 5 out of 5

    adrien.sortais28 (verified owner)

    Realy good ! thx

  4. Rated 5 out of 5

    19mato (verified owner)

    I ordered 2 and one was not working, but after i opened it, i found unsoldered connection on pot, soldered it and now it is working as intended. Would QA again 😀
