ESP-01 Prototype Breakout Board Kit

Description

Note:

• This board is a kit, NOT soldered, you must soldered by yourself.
• NOT include ESP-01 Board

Features:

• Lead all pins 2*4 out to breadboard
• One group of pin to connect VCC with CHPD to enable the module, by jumper
• One group of pin to connect RST with GND when you want to reset the module, by jumper
• On board current capacitor 220UF
• Only need a USB-TTL tool like CH340 breakout board to connect ESP-01: TX, RX, VCC, GND

Please follow the soldering steps below to solder, otherwise the small board maybe a little difficult to do:

First solder the pins on the top of the board

2. Solder the capacitor and connector

3. add jumper and esp-01 board

4. use it
