NRF24L01 – 2.4G-Wireless Module (Arduino supported)

NRF24L01 2.4G Wireless Module, Genuine Chip

A7105 2.4G Wireless Transceiver (MD7105)
4.67 out of 5
4 customer reviews|Add a review

$2.90

RF24L01B low power wireless module, use NRF24L01 chip from Nordic, 2.4G lisence-free ISM band, highest working data speed is 2Mbps,

SKU: NWL1053 Category: Tags: , ,

Description

Overview:

RF24L01+ low power wireless module, use  NRF24L01 chip from Nordic, 2.4G lisence-free ISM band, highest working data speed is 2Mbps, 125channels can reach different point or jump frequency communication needs, small size 18*37 mm, high efficiency GFSK modulation, anti-interfere, specially suit for indutrial control.

Feature:

  • 2.4Ghz  lisence-free ISM band
  • Highest data speed 2Mbps，high efficient GFSK modulation, anti-interfere, specially suit for indutrial control
  • 125 channel, can reach different point or jump frequency communication needs
  • Integrated hardware 8/16 bytes CRC confirmation and point to mutiple points communication adress control, combine TDMA – CMDA – FDMA working principle, enable wireless communication.
  • Low power comunpiton 1.9 – 3.6V ，Standby mode only need 1uA ；
  • Module can set address by software, only output data when receive own device address(display interruption), can directly connect to any single chip, easy to program.
  • Send and receive interruption signal, send 28 bytes maximally each time.
  • Integrated special voltage regulator, use any kind of power including DC/DC power can have better communication effort.
  • Standard DIP jack, easy for embedded system application.
  • CLK，DATA，DR three wires connection，easy to program。
  • Two channels data receive, embedded circular antennas, communication distance is 20-30 meters in open and no interferes environment.
  • Dimension: 34mm * 17mm * 1mm（PCB embedded antennas）

Applications:

Vehicle monitoring, remote control, telemetry, small wireless network, wireless access control systems, residential short range paging, industrial data acquisition systems,wireless tags, identification, non-contact RF smart card, a small wireless data terminals, security, fire systems, wireless remote control system, bio-signal acquisition, hydrological and meteorological monitoring, robot control, wireless 232 data communications, wireless digital audio, digital image transmission

This is only one piece of Nrf24l01

Documentation:

  • Most info at this Wiki page
  • Check out tutorials for Arduino here.

Additional information

Weight 0.003 kg

4 reviews for NRF24L01 2.4G Wireless Module, Genuine Chip

  1. Harry –

    These are very good modules. Use the RF24 library (not Mirf). Go to http://maniacbug.github.io/RF24/index.html to find all the information you need.

  2. 5 out of 5

    balaji –

    This is cool, works as expected. I will test the clone and give feedback.

  3. 5 out of 5

    remymorra (verified owner) –

    goood!!

  4. 4 out of 5

    galgoczki.adam@gmail.com (verified owner) –

    I bought 5 and all of them works. These products follows the pcb layout what you find in the datasheet of the nRF24l01 chip’s datasheet. I also designed pcb-s with the same layout and orderd them from a PCB maker factory, and those worked a bit better.
