USB PD Power Booster Supply for Breadboard, Trick Chip Sniffer

2PCs RC Snubber Board (AC Kickback circuits for Inductive Load)
1.00 out of 5
2 customer reviews|Add a review

$2.70

SKU: OPM1185 Category: Tags: , , ,

Description

The chip trap the 5V / 9V /12V / 15V / 20 V power supply from your USB PD adapter, or power bank. Power bank normally only up to 12V.

Normally output capability 3 – 1 A, for around 20W adapter.

Bring the power supply for protyping usage on breadboard, this board can directly plug into common breadboard.

Usage:

  • Turn on each corresponding switch to change the voltage:
  • 5V: turn off all the switch default | 9V: 51K | 12V: 100K | 15V: 150K | 20V: 180K
  • On board power LED indicator.
  • If no load is connected, connect 500-1K 1W resistor to keep the power bank running the output and not turn off.

Simple use guide please see on this page.

Additional information

Weight 0.01 kg

2 reviews for USB PD Power Booster Supply for Breadboard, Trick Chip Sniffer

  1. 1 out of 5

    Ian T Bell (verified owner) –

    Product only outputs 5V. Changing the switches to not change the output voltage

  2. 1 out of 5

    Chao (store manager) –

    Hi, we just made a demo video, you can take a look at here: https://fb.watch/9tHetohaKD/
