• Very mini size 27*40*4.5(±0.2)mm, easy for embedded projects.
  • Low-power dual-core 32-bit CPU for application processors
  • Main frequency up to 240MHz, computing power up to 600 DMIPS
  • Built-in 520 KB SRAM, external 4M PSRAM\
  • Supports interfaces such as UART/SPI/I2C/PWM/ADC/DAC
  • Support OV2640 and OV7670 cameras, built-in flash
  • Support image WiFi upload
  • Support TF card
  • Support multiple sleep modes
  • Embedded Lwip and FreeRTOS
  • Support STA/AP/STA+AP working mode
  • Support Smart Config/AirKiss One-click distribution network
  • Support secondary development


  • CPU: ESP32, Xtensa@32-bit LX6 dual-core processor, computing power up to 600DMIPS 448KByte
  • ROM: 520KByteSRAM RTC16KByte SRAM
  • General IO: 9
  • Package: DIP-16
  • Storage: SPIFlash default 32Mbit, 520K3SRAM+4MPSRAM
  • Support interface: LIART, SPI, 2C, PWM
  • Support TF card: Maximum support 4G
  • Serial port rate: default 115200bps
  • Image output format: JPEG (0v2640 only), BMP, GRAYSCALE
  • Spectrum range 2412 ~ 2484MHz
  • WiFi802.11: b/g/n/d/e/i/k/r (802.11n, speed up to 150Mbps) A-MPDU and A. MSDU aggregation, support 0.4us guard interval 2.4 to 2.5GHz
  • Bluetooth: V4.2BR/ER and BLE standards, NZIF receiver with -98dBm sensitivity, Class-1, Class-2 and Class-3 transmitters, support for AFH (Frequency Modulation), support for CVSD and SBC audio formats
  • Supply voltage: 5V2A

Documentation please see on this page.

Additional information

Weight 0.02 kg
